Two 18V LXT® batteries achieve a high voltage of 36V. (Batteries not Included)
Suited to impact and unstressed drilling and chipping. Speed range of 0 – 1 200 min⁻¹.
Impact energy of 2.5 J and max. drilling capacity of 26 mm in concrete.
36V performance from two 18V batteries connected in series.
The batteries are placed in parallel in separate battery docking stations.
One touch sliding chuck enables quick and easy bit changes
3-Mode operation for "Rotation Only", "Hammering with Rotation" or "Hammering Only" for multiple applications
Ergonomic chassis design ensures a good working position.
Reversing switch
LED light illuminates the work site
Battery protection circuit protects against overloading, over-discharging and over-heating
Max. Drilling Diameter in Concrete: 26 mm
Max. Drilling Diameter in Wood: 32 mm
Max. Drilling Diameter in Steel: 13 mm
Optimum Drilling Diameter Range in Concrete: 4 - 18 mm
Drilling diameter with TCT core bit: 54 mm
Voltage LXT
Nominal Battery Voltage: 2 x 18 V (Batteries Not Included)
Battery Chemistry (Ni-Cd / Ni-MH / Li-ion): Li-ion
Impact Energy: 2.5 J
Impacts per Minute (IPM): 0 - 5000 min⁻¹
No load speed: 0 - 1250 min⁻¹
Adapted for SDS-PLUS bits
Sound Power Level (LWA): 102 dB(A)
Sound Pressure Level (LpA): 94 dB(A)
Noise Uncertainty (K Factor): 3 dB(A)
Vibration Level, Hammer Drilling Into Concrete: 17.6 m/s²
Vibration Uncertainty (K Factor), Hammer Drilling Into Concrete: 1.8 m/s²
Vibration Level, Chiselling: 14.3 m/s²
Vibration Uncertainty (K Factor), Chiselling: 1.5 m/s²
Vibration Level, Drilling into metal: 3.0 m/s²
Vibration Uncertainty (K Factor), Drilling into metal: 1.5 m/s²
Product Dimensions (L x W x H): 350 x 116 x 232 mm
Tool weight with battery: 3.5 - 4.7 kg
