DHP492 Brushless Combi Drill 18v
A powerful, brushless and efficient general-use impact drill for screwdriving and drilling. A powerful max. torque of 141Nm.
Redesigned speed change mechanism to avoid gear disengagement
Controller protection has been revised to enhance the protection for electronic components during variable speed control by the trigger.
Highly efficient and compact machine for professional use
LED light illuminates the work site
Battery protection system automatically shuts off power when the battery level is low
Electronic overload protection protects the user and the device
Keyless chuck for easy bit installation and removal
Compact and lightweight for reduced operator fatigue
Electric brake for maximum productivity and increased operator safety
Max. Drilling Diameter in Masonry: 16 mm
Max. Drilling Diameter in Steel: 13 mm
Drilling Capacity Wood (Auger Bit): 50 mm
Drilling Capacity Wood (Self-feed bit): 76 mm
Drilling Capacity Flat bit: 40 mm
Drilling Capacity Hole Saw: 152 mm
Nominal Battery Voltage: 18 V
Voltage: LXT
Battery Chemistry (Ni-Cd / Ni-MH / Li-ion): Li-ion
Brushless Motor
No load speed: 0 - 550 / 2100 min⁻¹
Max. fastening torque Hard/Soft: 130 / 65 Nm
Max Torque: 141 Nm
Torque setting: 21
Impacts per Minute (IPM): 0 - 8250 / 31500 min⁻¹
Driving Shank: 1/2"-20UNF "
Drill Chuck Capacity: 1.5 - 13 mm
Electronic brake
Vibration Level, Drilling into metal: ≤ 2.5 m/s²
Vibration Uncertainty (K Factor), Drilling into metal: 1.5 m/s²
Vibration Level, Impact Drilling into Concrete: 8.6 m/s²
Vibration Uncertainty (K Factor), Impact Drilling into Concrete: 1.5 m/s²
Sound Power Level (LWA): 95 dB(A)
Sound Pressure Level (LpA): 87 dB(A)
Noise Uncertainty (K Factor): 3 dB(A)
Product Dimensions (L x W x H): 180 x 81 x 265 mm
Tool weight with battery: 2.3 - 2.7 kg
Product net weight: 1.7 kg
DTD173 Brushless 18v Impact Driver LXT
Electronic 4 stage impact power selection for added versatility
Well balanced with a low center of gravity for easy operation
Slim body design for a good grip
Electric brake for maximum productivity and increased operator safety
Anti wobbling bit structure
Nominal Battery Voltage: 18 V
Voltage LXT
Battery Chemistry (Ni-Cd / Ni-MH / Li-ion): Li-ion
Brushless Motor
No load speed: 0 - 1100 / 2100 / 3200 / 3600 min⁻¹
Max Fastening Torque Impact Drill: 20 / 50 / 170 / 180 Nm
Impacts per Minute (IPM): 0 - 1100 / 2600 / 3600 / 3800 min⁻¹
Tightening Capacity Standard Bolt: M5 - M16
Capacity machine screw: M4 - M8
Tightening Capacity High Tensile Bolt: M5 - M14
Driving Shank: 1/4 "
Sound Power Level (LWA): 108 dB(A)
Sound Pressure Level (LpA): 97 dB(A)
Noise Uncertainty (K Factor): 3 dB(A)
Vibration Level, Impact Tightening of Fasteners of the Maximum Capacity of the Tool: 12.9 m/s²
Vibration Uncertainty (K Factor), Impact Tightening of Fasteners of the Maximum Capacity of the Tool: 1.5 m/s²
Product Dimensions (L x W x H):111 x 81 x 234 mm
Tool weight with battery: 1.2 - 1.5 kg
Product net weight: 0.85 kg
