Nominal Battery Voltage: 18 V
Voltage LXT
Number of Batteries Supplied: 2
Battery Chemistry (Ni-Cd / Ni-MH / Li-ion): Li-ion
DHP492:
Max. Drilling Diameter in Masonry: 16 mm
Max. Drilling Diameter in Steel: 13 mm
Drilling Capacity Wood (Auger Bit): 50 mm
Drilling Capacity Wood (Self-feed bit): 76 mm
Drilling Capacity Flat bit: 40 mm
Drilling Capacity Hole Saw: 152 mm
Nominal Battery Voltage:18 V
Voltage LXT:
Battery Chemistry (Ni-Cd / Ni-MH / Li-ion):Li-ion
Brushless Motor
Electronic brake
No load speed:0 - 550 / 2100 min⁻¹
Max. fastening torque Hard/Soft: 130 / 65 Nm
Max Torque: 141 Nm
Torque setting: 21
Impacts per Minute (IPM):0 - 8250 / 31500 min⁻¹
Driving Shank:1/2"-20UNF "
Drill Chuck Capacity:1.5 - 13 mm
Vibration Level, Drilling into metal:≤ 2.5 m/s²
Vibration Uncertainty (K Factor), Drilling into metal: 1.5 m/s²
Vibration Level, Impact Drilling into Concrete: 8.6 m/s²
Vibration Uncertainty (K Factor), Impact Drilling into Concrete: 1.5 m/s²
Sound Power Level (LWA): 95 dB(A)
Sound Pressure Level (LpA): 87 dB(A)
Noise Uncertainty (K Factor): 3 dB(A)
Product Dimensions (L x W x H): 180 x 81 x 265 mm
Tool weight with battery: 2.3 - 2.7 kg
Product net weight: 1.7 kg
DTD201:
Voltage LXT
Nominal Battery Voltage: 18 V
Battery Chemistry (Ni-Cd / Ni-MH / Li-ion): Li-ion
No load speed: 0 - 1100 / 2100 / 3200 / 3700 min⁻¹
Max Fastening Torque Impact Drill: 20 / 150 / 190 / 210 Nm
Impacts per Minute (IPM): 0 - 2000 / 3600 / 4200 / 4400 min⁻¹
Tightening Capacity Standard Bolt: M5 - M16
Capacity machine screw: M4 - M8
Tightening Capacity High Tensile Bolt: M5 - M14
Driving Shank: 1/4 "
Sound Power Level (LWA): 105 dB(A)
Sound Pressure Level (LpA): 97 dB(A)
Noise Uncertainty (K Factor): 3 dB(A)
Vibration Level, Impact Tightening of Fasteners of the Maximum Capacity of the Tool: 9.9 m/s²
Vibration Uncertainty (K Factor), Impact Tightening of Fasteners of the Maximum Capacity of the Tool: 1.5 m/s²
Product Dimensions (L x W x H): 121 x 81 x 246 mm
Tool weight with battery: 1.3 - 1.7 kg
Product net weight: 0.98 kg
