Cutting depth adjustment
Tilting base for bevel cuts from 0° - 45°
Built-in dust blower clears the line of cut for greater accuracy
The rubber coating on the handle ensures a firm working grip
Battery protection system automatically shuts off power when the battery level is low
CXT Battery (Battery not Included)
Blade Diameter: 85 mm
Bore Size (Arbor Diameter): 15 mm
No load speed: 1500 min⁻¹
Max. Cutting Depth at 90°: 25.5 mm
Max. Cutting Depth at 45°: 16.5 mm
Sound Power Level (LWA): 97 dB(A)
Sound Pressure Level (LpA): 86 dB(A)
Noise Uncertainty (K Factor): 3 dB(A)
Tool weight with battery: 1.6 - 1.7 kg
Product Dimensions (L x W x H): 313 x 170 x 155 mm
Nominal Battery Voltage: 12 V
Battery Chemistry (Ni-Cd / Ni-MH / Li-ion): Li-ion
Max. Bevel Range (Right): 0 - 45 º
Vibration Level, Cutting Wood: ≤ 2.5 m/s²
Vibration Uncertainty (K Factor), Cutting Wood: 1.5 m/s²
Vacuum cleaner connection Ø in / out: 25 / 31 mm
