Redesigned speed change mechanism to avoid gear disengagement
Controller protection has been revised to enhance the protection for electronic components during variable speed control by the trigger.
Highly efficient and compact machine for professional use
LED light illuminates the work site
Battery protection system automatically shuts off power when the battery level is low
Electronic overload protection protects the user and the device
Keyless chuck for easy bit installation and removal
Compact and lightweight for reduced operator fatigue
Electric brake for maximum productivity and increased operator safety
Max. Drilling Diameter in Masonry: 16 mm
Max. Drilling Diameter in Steel: 13 mm
Drilling Capacity Wood (Auger Bit): 50 mm
Drilling Capacity Wood (Self-feed bit): 76 mm
Drilling Capacity Flat bit: 40 mm
Drilling Capacity Hole Saw: 152 mm
Nominal Battery Voltage: 18 V (Battery not Included)
Voltage: LXT
Battery Chemistry (Ni-Cd / Ni-MH / Li-ion): Li-ion
Brushless Motor
No load speed: 0 - 550 / 2100 min⁻¹
Max. fastening torque Hard/Soft: 130 / 65 Nm
Max Torque: 141 Nm
Torque setting: 21
Impacts per Minute (IPM): 0 - 8250 / 31500 min⁻¹
Driving Shank: 1/2"-20UNF "
Drill Chuck Capacity: 1.5 - 13 mm
Electronic brake
Vibration Level, Drilling into metal: ≤ 2.5 m/s²
Vibration Uncertainty (K Factor), Drilling into metal: 1.5 m/s²
Vibration Level, Impact Drilling into Concrete: 8.6 m/s²
Vibration Uncertainty (K Factor), Impact Drilling into Concrete: 1.5 m/s²
Sound Power Level (LWA): 95 dB(A)
Sound Pressure Level (LpA): 87 dB(A)
Noise Uncertainty (K Factor): 3 dB(A)
Product Dimensions (L x W x H): 180 x 81 x 265 mm
Tool weight with battery: 2.3 - 2.7 kg
Product net weight: 1.7 kg
