DHP492 - A powerful, brushless and efficient general-use impact drill for screwdriving and drilling. A powerful max. torque of 141Nm.
Redesigned speed change mechanism to avoid gear disengagement
Controller protection has been revised to enhance the protection for electronic components during variable speed control by the trigger.
Highly efficient and compact machine for professional use
LED light illuminates the work site
Battery protection system automatically shuts off power when the battery level is low
Electronic overload protection protects the user and the device
Keyless chuck for easy bit installation and removal
Compact and lightweight for reduced operator fatigue
Electric brake for maximum productivity and increased operator safety
Max. Drilling Diameter in Masonry: 16 mm
Max. Drilling Diameter in Steel: 13 mm
Drilling Capacity Wood (Auger Bit): 50 mm
Drilling Capacity Wood (Self-feed bit): 76 mm
Drilling Capacity Flat bit: 40 mm
Drilling Capacity Hole Saw: 152 mm
Nominal Battery Voltage: 18 V
Voltage: LXT
Battery Chemistry (Ni-Cd / Ni-MH / Li-ion): Li-ion
Brushless Motor
No load speed: 0 - 550 / 2100 min⁻¹
Max. fastening torque Hard/Soft: 130 / 65 Nm
Max Torque: 141 Nm
Torque setting: 21
Impacts per Minute (IPM): 0 - 8250 / 31500 min⁻¹
Driving Shank: 1/2"-20UNF "
Drill Chuck Capacity: 1.5 - 13 mm
Electronic brake
Vibration Level, Drilling into metal: ≤ 2.5 m/s²
Vibration Uncertainty (K Factor), Drilling into metal: 1.5 m/s²
Vibration Level, Impact Drilling into Concrete: 8.6 m/s²
Vibration Uncertainty (K Factor), Impact Drilling into Concrete: 1.5 m/s²
Sound Power Level (LWA): 95 dB(A)
Sound Pressure Level (LpA): 87 dB(A)
Noise Uncertainty (K Factor): 3 dB(A)
Product Dimensions (L x W x H): 180 x 81 x 265 mm
Tool weight with battery: 2.3 - 2.7 kg
Product net weight: 1.7 kg
DTW300 - The Makita DTW300Z is powerful and extra-compact, 144 mm-long, 1/2" drive impact wrench. Small size and light weight make this tool easy to use, while offering a max. fastening torque of 330 Nm. Four power settings.
The Makita DTW300Z has an electric brake
Variable speed control by trigger
Forward / reverse rotation
LED job light
Brushless motor
Electronic 4 stage impact power selection
Trigger switch with full speed mode: Variable speed mode can be changed to full speed mode simply by pushing a button. Because in full speed mode the trigger travel is shorter , the full speed is reached faster.
Auto-stop system available both in forward/reverse rotation modes
Makita DTW300Z Specifications:
Nominal Battery Voltage: 18 V
Voltage LXT
Max Fastening Torque Impact Drill: 100 / 160 / 210 / 330 Nm
No load speed: 0 - 1000 / 1800 / 2600 / 3200 min⁻¹
Impacts per Minute (IPM): 0 - 1800 / 2600 / 3400 / 4000 min⁻¹
Drive Square: 1/2 "
Tightening Capacity Standard Bolt: M10 - M20
Tightening Capacity High Tensile Bolt: M10 - M16
Sound Power Level (LWA): 108 dB(A)
Sound Pressure Level (LpA): 97 dB(A)
Noise Uncertainty (K Factor): 3 dB(A)
Vibration Level (3 axes), Fastening Bolt: 12.5 m/s²
Vibration Uncertainty (K Factor): 1.5 m/s²
Tool weight with battery:1.5 - 1.8 kg
Product Dimensions (L x W x H): 144 x 81 x 246 mm
Brushless Motor
Nut-busting torque: 580 Nm
Max Output Power: 420 W
Product net weight: 1.2 kg
Previous model the scaffolders favourite. Updated.: DTW285
