Power transmission by toothed belt ensures the right blade speed for the job with approx. a doubling of torque.
Cutting performance in wood up to 8mm, plastics (also PERTINAX printed circuit boards) up to approx. 3mm, non-ferrous metals up to approx. 1.5mm.
Even fibreglass reinforced PC cards can be cut by using a carbide saw blade.
Adjustable mitre fence with scale. Angle stop with degree graduation.
Flat-milled worktop of die-cast aluminium (160 x 160mm).
1. Graduated mitre stop.
2. Machined, die-cast aluminium table of 160 x 160mm.
3. Motor: low noise and persevering for prolonged use.
4. Base of ABS with a sawdust door on the right.
5. 'Super-Cut' blade (58mm diameter), 80 teeth, individually set and sharpened, is included.
6. Adjustable fence with scale
Technical Data:
230V.
85 W.
8,000rpm.
Weight approx 1.8kg.
