Speed range of 0 – 950 min⁻¹. Impact energy of 2.0 J and max. drilling capacity of 24 mm in concrete.
3-Mode operation for "Rotation Only", "Hammering with Rotation" or "Hammering Only" for multiple applications
Brushless maintenance-free and long-life motor
Battery protection circuit protects against overloading, over-discharging and over-heating
Optimum Drilling Diameter Range in Concrete: 4 - 16 mm
Max. Drilling Diameter in Concrete: 24 mm
Max. Drilling Diameter in Wood: 27 mm
Max. Drilling Diameter in Steel: 13 mm
Nominal Battery Voltage: 18 V (Battery not included)
Voltage LXT
Battery Chemistry (Ni-Cd / Ni-MH / Li-ion): Li-ion
Brushless Motor
Impact Energy: 2.0 J
Impacts per Minute (IPM): 0 - 4700 min⁻¹
No load speed: 0 - 950 min⁻¹
Drilling diameter with TCT core bit: 54 mm
Adapted for SDS-PLUS bits
Tool weight with battery: 3.4 - 4.9 kg
Electronic brake
Vibration Level, Hammer Drilling Into Concrete: 15.8 m/s²
Vibration Uncertainty (K Factor), Hammer Drilling Into Concrete: 1.5 m/s²
Vibration Level, Chiselling: 11.2 m/s²
Vibration Uncertainty (K Factor), Chiselling: 1.5 m/s²
Sound Power Level (LWA): 100 dB(A)
Sound Pressure Level (LpA): 89 dB(A)
Noise Uncertainty (K Factor): 3 dB(A)
Product Dimensions (L x W x H): 353 x 85 x 213 mm
Vibration Level, Drilling into metal: 2.5 m/s²
Vibration Uncertainty (K Factor), Drilling into metal: 1.5 m/s²
